Manufacturer of ANSI B16.5 Large Diameter Flange and Large Diameter Pipe Flanges in ASME B16.5 Class 150 Lb, 300 Lb, 400 Lb, 600 Lb, 900 Lb, 1500 Lb and 2500 Lb as per ASME/ ASA/ ANSI B16.5
Rajendra Industrial Corporation is one of the best distributors in the world, dealing with a big number of customers and striving diligently to manufacture, supply, and supply a decent diversity of Large Diameter Flanges all over the globe. These Big Diameter Flanges are available in a variety of specifications, including standards, dimensions, sizes, classifications, and more. Large diameter flanges are used to join or separate two pipes with very large diameters. Large diameter Slip-on, Lap Joint, Weld Neck, and Blind Flanges are in stock, and we can additionally obtain a range of sizes and classes for lengthier lead times, ranging from 12" to 60". A large diameter flange is a metallic ring that is used to link valves, pipes, pumps, and other pipeline-related apparatus. The Large Diameter flange also makes pipe inspection, modification, and cleaning simple and quick.
Table Of Contents
Carbon steel that has been thoroughly forged and machined surfaces is the most common material used to make SS Big Diameter Flanges. Flanges can be produced in a variety of methods. Some people have lips and others don't. To prevent pipeline leaks, nearly every type of flange has a seal attached to it. Large Diameter Flanges offer a wide range of applications and are highly resistant to corrosion. Flanges with large diameters are an important feature of the pipeline system. These Large Diameter Flanges are easy to install in any weather or trench condition, including underwater! Elastomeric sealing gaskets are made to survive for at least 50 years. We, Rajendra Industrial Corporation, manufacture high-quality Large Diameter Flanges under the supervision of skilled specialists with extensive product development experience. Flange production begins with the use of high-quality alloys, cutting-edge technology, and cutting-edge tools.
| Size | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
|---|---|
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF) |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Material | Inconel Large Diameter Flange, Hastelloy Large Diameter Flange, AISI 4130 Large Diameter Flange, Incoloy Big Diameter Flange, Nickel Alloy Large Diameter Flange, Titanium Big Diameter Flange, Super Duplex Big Diameter Flange, Brass Large Diameter Flange, Alloy 20 Large Diameter Flange, Duplex Steel Large Diameter Flange, Monel Large Diameter Flange, SMO 254 Big Diameter Flange, Stainless Steel Big Diameter Flange, Copper Nickel Large Diameter Flange. |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Stainless Steel Large Diameter Flanges
Alloy Steel Big Diameter Flanges
Carbon Steel Large Diameter Flanges
Duplex Steel Large Diameter Flanges
Super Duplex Steel Large Diameter Flanges
Nickel Alloy Big Diameter Flanges
Monel Big Diameter Flanges
Hastelloy Large Diameter Flanges
Inconel Large Diameter Flanges
Titanium Big Diameter Flanges
Alloy 20 Large Diameter Flanges
Copper Nickel Large Diameter Flanges
Manufacturer of ANSI B16.5 Large Diameter Flange and Large Diameter Pipe Flanges in ASME B16.5 Class 150 Lb, 300 Lb, 400 Lb, 600 Lb, 900 Lb, 1500 Lb and 2500 Lb as per ASME/ ASA/ ANSI B16.5
| Price list of ASME B16.47 Series A Large Diameter Flange | US $0.5-1000 / Piece (FOB Price) |
| ANSI B16.5 Class 150 Large Diameter Flanges Price in India | US $300-500 / Ton (FOB Price) |
| Price list of Large Diameter Flanges | US $1-900 / Piece (FOB Price) |
| Stainless Steel Large Diameter Flanges Price | US $0.5-1000 / Piece (FOB Price) |
| FF Flange Price List | US $1-300 / Piece (FOB Price) |
| Big Diameter Flange Price Per Piece in India | US $1-800 / Piece (FOB Price) |
| ASME B16.5 Class 300 Raised Faced Large Diameter Flanges Price | US $15-900 / Piece (FOB Price) |
| Price of Large Diameter Faced Flanges EN 1092-1 Type 02 | US $20-1500 / Piece (FOB Price) |
| EN 1092-2 PN16 Big Diameter Flange Price List | US $26-2000 / Piece (FOB Price) |
| Large Diameter C207 Class d Large Diameter Flange Price | US $18-1800 / Piece (FOB Price) |
We can supply BS 4504 PN10 Big Diameter Flanges with customized Class / Pressure and sizes, view EN 1092-1 Type 02 Class 150 Big Diameter Flange Price.
| NPS | Pipe Diameter | Flange Inside Daimeter | Number of holes | Flange Daimeter | Thickness of Flange | Daimeter of Bolt Circle | Daimeter of Bolt Holes | Approx.Weight in kg | |
| DN | ISO | DIN | D5 | BN | D | b | K | d2 | KG/PCS |
| 10 | – | 14 | 14.5 | 4 | 90 | 16 | 60 | 14 | 0.7 |
| 17.2 | – | 17.7 | 4 | 90 | 16 | 60 | 14 | 0.69 | |
| 15 | – | 20 | 21 | 4 | 95 | 16 | 65 | 14 | 0.77 |
| 21.3 | – | 22 | 4 | 95 | 16 | 65 | 14 | 0.77 | |
| 20 | – | 25 | 26 | 4 | 105 | 18 | 75 | 14 | 1.06 |
| 26.9 | – | 27.6 | 4 | 105 | 18 | 75 | 14 | 1.05 | |
| 25 | – | 30 | 31 | 4 | 115 | 18 | 85 | 14 | 1.27 |
| 33.7 | – | 34.4 | 4 | 115 | 18 | 85 | 14 | 1.25 | |
| 32 | – | 38 | 39 | 4 | 140 | 18 | 100 | 18 | 1.86 |
| 42.4 | – | 43.1 | 4 | 140 | 18 | 100 | 18 | 1.83 | |
| 40 | – | 44.5 | 45.5 | 4 | 150 | 18 | 110 | 18 | 2.12 |
| 48.3 | – | 49 | 4 | 150 | 18 | 110 | 18 | 2.09 | |
| 50 | – | 57 | 58.1 | 4 | 165 | 20 | 125 | 18 | 2.78 |
| 60.3 | – | 61.1 | 4 | 165 | 20 | 125 | 18 | 2.74 | |
| 65 | 76.1 | – | 77.1 | 8 | 185 | 22 | 145 | 18 | 3.48 |
| 80 | 88.9 | – | 90.3 | 8 | 200 | 24 | 160 | 18 | 4.33 |
| 100 | – | 108 | 109.6 | 8 | 235 | 24 | 190 | 22 | 5.82 |
| 114.3 | – | 115.9 | 8 | 235 | 24 | 190 | 22 | 5.61 | |
| 125 | – | 133 | 134.8 | 8 | 270 | 26 | 220 | 26 | 7.91 |
| 139.7 | – | 141.6 | 8 | 270 | 26 | 220 | 26 | 7.6 | |
| 150 | – | 159 | 161.1 | 8 | 300 | 28 | 250 | 26 | 10.12 |
| 168.3 | – | 170.5 | 8 | 300 | 28 | 250 | 26 | 9.58 | |
| 175 | 193.7 | – | 196.1 | 12 | 350 | 32 | 295 | 30 | 14.45 |
| 200 | 219.1 | – | 221.8 | 12 | 375 | 34 | 320 | 30 | 16.9 |
| 250 | – | 267 | 270.2 | 12 | 450 | 38 | 385 | 33 | 27.28 |
| 273 | – | 276.2 | 12 | 450 | 38 | 385 | 33 | 26.51 | |
| 300 | 323.9 | – | 327.6 | 16 | 515 | 42 | 450 | 33 | 36.38 |
| 350 | 355.6 | – | 359.7 | 16 | 580 | 46 | 510 | 36 | 52.83 |
| – | 368 | 372.2 | 16 | 580 | 46 | 510 | 36 | 50.24 | |
| 400 | 406.4 | – | 411 | 16 | 660 | 50 | 585 | 39 | 74.71 |
| – | 419 | 423.7 | 16 | 660 | 50 | 585 | 39 | 71.44 | |
| 500 | 508 | – | 513.6 | 20 | 755 | 52 | 670 | 42 | 86.87 |
| 600 | 610 | – | 616.5 | 20 | 890 | 54 | 795 | 48 | 121.84 |
| 700 | 711 | – | 716 | 24 | 995 | 58 | 900 | 48 | 150.93 |
| 800 | 813 | – | 818 | 24 | 1140 | 64 | 1030 | 56 | 219.08 |
| 900 | 914 | – | 920 | 28 | 1250 | 70 | 1140 | 56 | 271.16 |
| 1000 | 1016 | – | 1022 | 28 | 1360 | 78 | 1250 | 56 | 344.95 |
| NPS | Dimensions Of Flange | Bolts Size |
Weight of one flange 7.85 kilogram/ dm3) kilogram |
|||||||
| NW | d1 | ds | D | b1 | k | Number | Thread | d2 | ||
| 10 |
14 17.2) |
14.5 17.7 |
90 | 14 | 60 | 4 | M12 | (1/2") | 14 |
0.613 0.605 |
| 15 |
20 21.3) |
20.5 21.8 |
95 | 14 | 65 | 4 | M12 | (1/2") | 14 |
0675 0.669 |
| 20 |
25 26.9) |
25.5 27.4 |
105 | 16 | 75 | 4 | M12 | (1/2") | 14 |
0.947 0.936 |
| 25 |
30 33.7) |
30.5 34.2 |
115 | 16 | 85 | 4 | M12 | (1/2") | 14 |
1.14 1.11 |
| 32 |
38 42.4) |
38.5 42.9 |
140 | 16 | 100 | 4 | M16 | (5/8") | 18 |
1.66 1.62 |
| 40 |
44.5 48.3) |
45 48.8 |
150 | 16 | 110 | 4 | M16 | (5/8") | 18 |
1.89 1.86 |
| 50 |
57 60.3) |
57.5 60.8 |
165 | 18 | 125 | 4 | M16 | (5/8") | 18 |
2.51 2.47 |
| 65 | 76.1) | 76.6 | 185 | 18 | 145 | 4 | M16 | (5/8") | 18 | 3.00 |
| 80 | 88.9) | 89.4 | 200 | 20 | 160 | 4 | M16 | (5/8") | 18 | 3.79 |
| 100 |
108 114.3) |
108.5 114.8 |
220 | 20 | 180 | 8 | M16 | (5/8") | 18 |
4.20 4.03 |
| 125 |
133 139.7) |
133.5 140.2 |
250 | 22 | 210 | 8 | M16 | (5/8") | 18 |
5.71 5.46 |
| 150 |
159 168.3) |
159.5 168.8 |
285 | 22 | 210 | 8 | M16 | (3/4") | 23 |
6.72 6.57 |
| 175 |
191 193.7) |
192 194.7 |
315 | 24 | 270 | 8 | M20 | (3/4") | 23 |
8.60 8.45 |
| 200 |
216 219.1) |
216 220.1 |
340 | 24 | 295 | 8 | M20 | (3/4") | 23 |
9.50 9.31 |
| 250 |
267 273) |
268 274 |
395 | 26 | 350 | 12 | M20 | (3/4") | 23 |
12.5 11.9 |
| 400 |
406.4 419 |
407.4 420 |
565 | 32 | 515 | 16 | M24 | (7/8") | 27 |
27.9 25.9 |
| 500 |
508) 521 |
509 522 |
670 | 38 | 620 | 20 | M24 | (7/8") | 27 |
37.9 41.1 |
| Temperature (°C) |
Class | ||||||
|---|---|---|---|---|---|---|---|
| Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class 1500 | Class 2500 | |
| -29 - 38 | 19.8 | 51.7 | 68.9 | 103.4 | 155 | 259 | 431 |
| 50 | 19.5 | 51.7 | 68.9 | 103.4 | 155 | 259 | 431 |
| 100 | 17.7 | 51.5 | 68.7 | 103.0 | 155 | 258 | 429 |
| 150 | 15.8 | 50.2 | 66.8 | 100.3 | 151 | 251 | 418 |
| 200 | 13.8 | 48.6 | 64.8 | 97.2 | 146 | 243 | 405 |
| 250 | 12.1 | 46.3 | 61.7 | 92.7 | 139 | 232 | 386 |
| 300 | 10.2 | 42.9 | 57.0 | 85.7 | 129 | 214 | 357 |
| 325 | 9.3 | 41.4 | 55.0 | 82.6 | 124 | 207 | 344 |
| 350 | 8.4 | 40.0 | 53.4 | 80.0 | 120 | 200 | 334 |
| 375 | 7.4 | 37.8 | 50.4 | 75.7 | 114 | 189 | 315 |
| 400 | 6.5 | 34.7 | 46.3 | 69.4 | 104 | 174 | 290 |
| 425 | 5.5 | 28.8 | 38.4 | 57.5 | 86.3 | 144 | 240 |
| 450 | 4.6 | 23.0 | 30.7 | 46.0 | 69.0 | 115 | 192 |
| 475 | 3.7 | 17.1 | 22.8 | 34.2 | 51.3 | 85.4 | 142 |
| 500 | 2.8 | 11.6 | 15.4 | 23.2 | 34.7 | 57.9 | 96.5 |
| 538 | 1.4 | 5.9 | 7.9 | 11.8 | 17.7 | 29.5 | 49.2 |
| ANSI B16.5 Large Diameter Face Flange Wall Thickness | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NPS (Normal Pipe Sizes) | Outside Daimeter (O.D.) | Schedule 10 | Schedule 20 | Schedule 30 | STD Wall | Schedule 40 | Schedule 60 | EXT Hvy | Schedule 80 | Schedule 100 | Schedule 120 | Schedule 140 | Schedule 160 | XX Hvy |
| ½ | 0.84 | 0.083 | ... | ... | 0.109 | 0.109 | ... | 0.147 | 0.147 | ... | ... | ... | 0.188 | 0.294 |
| ¾ | 1.05 | 0.083 | ... | ... | 0.113 | 0.113 | ... | 0.154 | 0.154 | ... | ... | ... | 0.219 | 0.308 |
| 1 | 1.315 | 0.109 | ... | ... | 0.133 | 0.133 | ... | 0.179 | 0.179 | ... | ... | ... | 0.25 | 0.358 |
| 1 ¼ | 1.66 | 0.109 | ... | ... | 0.14 | 0.14 | ... | 0.191 | 0.191 | ... | ... | ... | 0.25 | 0.382 |
| 1 ½ | 1.9 | 0.109 | ... | ... | 0.145 | 0.145 | ... | 0.2 | 0.2 | ... | ... | ... | 0.281 | 0.4 |
| 2 | 2.375 | 0.109 | ... | ... | 0.154 | 0.154 | ... | 0.218 | 0.218 | ... | ... | ... | 0.344 | 0.436 |
| 2 ½ | 2.875 | 0.12 | ... | ... | 0.203 | 0.203 | ... | 0.276 | 0.276 | ... | ... | ... | 0.375 | 0.552 |
| 3 | 3.5 | 0.12 | ... | ... | 0.216 | 0.216 | ... | 0.3 | 0.3 | ... | ... | ... | 0.438 | 0.6 |
| 3 ½ | 4 | 0.12 | ... | ... | 0.226 | 0.226 | ... | 0.318 | 0.318 | ... | ... | ... | ... | 0.636 |
| 4 | 4.5 | 0.12 | ... | ... | 0.237 | 0.237 | ... | 0.337 | 0.337 | ... | 0.438 | ... | 0.531 | 0.674 |
| 5 | 5.563 | 0.134 | ... | ... | 0.258 | 0.258 | ... | 0.375 | 0.375 | ... | 0.5 | ... | 0.625 | 0.75 |
| 6 | 6.625 | 0.134 | ... | ... | 0.28 | 0.28 | ... | 0.432 | 0.432 | ... | 0.562 | ... | 0.719 | 0.864 |
| 8 | 8.625 | 0.148 | 0.25 | 0.277 | 0.322 | 0.322 | 0.406 | 0.5 | 0.5 | 0.594 | 0.719 | 0.812 | 0.906 | 0.875 |
| 10 | 10.75 | 0.165 | 0.25 | 0.307 | 0.365 | 0.365 | 0.5 | 0.5 | 0.594 | 0.719 | 0.844 | 1 | 1.125 | 1 |
| 12 | 12.75 | 0.18 | 0.25 | 0.33 | 0.375 | 0.406 | 0.562 | 0.5 | 0.688 | 0.844 | 1 | 1.125 | 1.312 | 1 |
| 14 | 14 | 0.25 | 0.312 | 0.375 | 0.375 | 0.438 | 0.594 | 0.5 | 0.75 | 0.938 | 1.094 | 1.25 | 1.406 | ... |
| 16 | 16 | 0.25 | 0.312 | 0.375 | 0.375 | 0.5 | 0.656 | 0.5 | 0.844 | 1.031 | 1.219 | 1.438 | 1.594 | ... |
| 18 | 18 | 0.25 | 0.312 | 0.438 | 0.375 | 0.562 | 0.75 | 0.5 | 0.938 | 1.156 | 1.375 | 1.562 | 1.781 | ... |
| 20 | 20 | 0.25 | 0.375 | 0.5 | 0.375 | 0.594 | 0.812 | 0.5 | 1.031 | 1.281 | 1.5 | 1.75 | 1.969 | ... |
| 22 | 22 | 0.25 | ... | ... | 0.375 | ... | ... | 0.5 | ... | ... | .... | .... | .... | .... |
| 24 | 24 | 0.25 | 0.375 | 0.562 | 0.375 | 0.688 | 0.969 | 0.5 | 1.219 | 1.531 | 1.812 | 2.062 | 2.344 | .... |
| 26 | 26 | .... | .... | .... | 0.375 | .... | .... | 0.5 | .... | .... | .... | .... | .... | .... |
| 30 | 30 | 0.312 | 0.5 | 0.625 | 0.375 | .... | .... | 0.5 | .... | .... | .... | .... | .... | .... |
| 36 | 36 | 0.312 | 0.5 | 0.625 | 0.375 | 0.75 | .... | 0.5 | .... | .... | .... | .... | .... | .... |
| 40 | 40 | .... | .... | .... | 0.375 | .... | .... | 0.5 | .... | .... | .... | .... | .... | .... |
| 42 | 42 | …….. | …….. | …….. | 0.375 | …….. | …….. | 0.5 | …….. | …….. | …….. | …….. | …….. | …….. |
| 48 | 48 | …….. | …….. | …….. | 0.375 | …….. | …….. | 0.5 | …….. | …….. | …….. | …….. | …….. | …….. |
The final process of dispatch is the most tedious of all, and heavy duty cranes are used for it. With the help of our extensive delivery chain we can ensure time critical deliveries at the behest of our esteemed clients.
Our all Large Diameter Flange packed with seaworthy packing method then delivery to customers, usually the packing way include wooden box, wooden pallet. We make sure that it is seaworthy, strong, waterproof and easy for loading and unloading.
| Class 1500 Large Diameter Flanges Distributor in Mumbai | ASME B16.5 Large Diameter Flanges Exporter |
| ASME B16.5 Large Diameter Flange | Large Diameter Flange Supplier in India |
| 4 inch Stainless Steel Large Diameter Flange | Large Diameter Flanges Stockholder |
| ANSI B16.5 Large Diameter Flanges Wholesaler | EN 1092-1 Large Diameter Flanges Supplier |
| Alloy 20 Big Diameter Flanges | Copper Nickel Large Diameter Flanges at Best Price |
| JIS 10K Large Diameter Flange Supplier in Mumbai | MS Large Diameter Flange Table E |
| JIS 5K Large Diameter Flange Dimensions | 30 Inch Big Diameter Flange Dimensions |
| Carbon Steel Large Diameter Large Diameter Pipe Flange | ANSI #150 RTJ Large Diameter Flange Supplier |
| ASME SA105N Raised Faced Big Diameter Flanges | 18 inch Class 150 Carbon Steel Large Diameter Flange |
| EN 1092-2 PN16 Large Diameter Flange Stockist in India | Large Diameter C207 Class D Big Diameter Flange |
| ANSI B16.5 Class 150 Large Diameter Flange | ASME B16.47 Series B FF Flanges Dealer in India |
| ASME B16.5 Class 300 Large Diameter Flanges Stockist | Titanium Large Diameter Faced Flanges |
| ASME B16.5 Large Diameter Flange Manufacturer | 150# Large Diameter Face Flange Manufacturer |
| JIS 16K Large Diameter Flange Dealer | DIN 86029 PN10 Large Diameter Flange Manufacturer |
| Duplex Steel Big Diameter Flanges Supplier in Mumbai | SS Large Diameter Flange 150LBS |
| 8 Inch Large Diameter Flanges | ANSI B16.5 150 LBS Large Diameter Flanges |
| 18 inch Class 150 Carbon Steel FF Flange | Big Diameter C207 Flanges |
| DIN 2503 PN25 Large Diameter Flanges Supplier | Suppliers of DIN 2543 PN16 Large Diameter Flanges |
| ASME B16.5 Class 600 Raised Faced Large Diameter Flanges | Large Diameter Flange Exporter |
| Stainless Steel Large Diameter Flange | ASTM B564 Raised Faced Large Diameter Flanges |
| Table E Large Diameter Pipe Flanges Supplier in Mumbai | Class 1500 Large Diameter Flange Dimensions |
| EN 1092-2 Female Large Diameter Flanges | Carbon Steel Raised Face Large Diameter Flange Stockist |
| Raised Face Large Diameter Flange Manufacturer | ANSI B16.5 Weld Neck Large Diameter Flange |
| PN16 Large Diameter Flange Dimensions | Table D Large Diameter Flange Dimensions |
| Class 900 Big Diameter Flange Dimensions | Duplex Steel Large Diameter Flanges |
| BS 4504 PN10 Large Diameter Flanges Supplier in Mumbai | Alloy Steel Large Diameter Flanges Manufacturer in India |
| ASME B16.47 Series A Large Diameter Flange Manufacturer | JIS 10K Large Diameter Flanges |
| JIS B2220 10K Large Diameter Flange | PN 10 Male Large Diameter Flanges |
| Nickel Alloy Big Diameter Plate Flange | Mild Steel Large Diameter Flange |
| JIS B2220 5K 10K 16K Large Diameter Flanges | DIN Standard PN25 Large Diameter Flanges |
inconel big diameter flanges wholesaler, 150 lb large diameter flange dimensions, large diameter flange price in ahmedabad, large diameter flanges manufacturers in india, table e large diameter flange dimensions, nickel alloy large diameter flange price list in india, large diameter flanges manufacturer in mumbai, large diameter flanges manufacturer in india, hastelloy large diameter flanges manufacturer in mumbai, class 900 large diameter flange dimensions, incoloy large diameter flanges distributor, dimensions of large diameter flange, smo 254 large diameter flange price list, large diameter flange weight chart in kg, large diameter flange at best price in india, large diameter flange dimensions mm, large diameter flange thickness, alloy 20 large diameter flanges manufacturer, ansi b 16.5 large diameter flange dimensions, super duplex steel large diameter flanges, big diameter flange ansi b16.5 class 150, alloy steel large diameter flanges supplier, pn16 large diameter flange dimensions, titanium big diameter flanges stockist in mumbai, monel large diameter flanges exporter, large diameter flanges supplier in mumbai, large diameter flange dn80 pn10, large diameter flange dimensions in mm, class 900# large diameter flanges stock, large diameter flanges stockist in mumbai, large diameter flange dealer in gujarat, class 600# large diameter flanges exporter, duplex steel large diameter flanges supplier in india, large diameter flanges dealer, biggest large diameter flange manufacturer in india, en 1092-1 large diameter flange, large diameter class 300 flange price list in india, large diameter flange price list in mumbai, class 1500# large diameter face flanges, large diameter flanges manufacturer in rajkot, big diameter flange din 2576 pn16, large diameter flange price, large diameter flange 150 lbs dimensions, large diameter class 300 flanges traders, asme b16.5 ss large diameter flange, nickel alloy big diameter flange supplier in mumbai, large diameter flange dimensions 300#, table d big diameter flange dimensions, asme b16.47 large diameter flange dimensions, bs10 table d large diameter flange, large diameter flange price list philippines, carbon steel large diameter flange manufacturer, copper nickel large diameter manufacturer in mumbai, large diameter flange distribution, large diameter flange din 2576 pn10, jis 5k large diameter flange dimensions, large diameter flange jis 5k, 1/2 big diameter flange, price of stainless steel large diameter flanges, large diameter flanges stockholder, stainless steel large diameter flanges importer, big diameter pipe flanges supplier in india, cost of large diameter flange, 30 inch large diameter flange dimensions, ms large diameter flange, asme 16.5 large diameter flanges stockholder, large diameter c207 flanges dealer, class 600 large diameter flange dimensions.
| Bengaluru | Mumbai | Chennai | Hyderabad | Kolkata | Pune |
| New Delhi | Ahmedabad | Jaipur | Surat | Salem | Gandhinagar |
| Bhiwandi | Tiruppur | Sivakasi | Jamnagar | Thiruvananthapuram | Rajahmundry |
| Bhubaneswar | Vijaywada | Firozabad | Bokaro Steel City | Rajkot | Bharuch |
| Panna | Raipur | Cochin | Ludhiana | Panipat | Durgapur |
| Peenya | Pimpri-Chinchwad | Channapatna | Kharagpur | Nashik | Bareilly |
| Varanasi | Haldia | Rourkela | Bangalore | Moradabad | Indore |
| Visakhapatnam | Trivandrum | Pithampur | Dibrugarh | Angul | Gwalior |
| Coimbatore | Kannur | Nagpur | Vadodara | Rudrapur | Noida |
| Agra | Bhagalpur | Jamshedpur | Bhilai | Lucknow | Kanpur |
| Thane | Bhopal | Sri City | Bareilly | Hosdurg | Pithampur |
Rajendra Industrial Corporation is a highly acclaimed manufacturer, supplier and exporter of Stainless Steel Flanges, Carbon Steel Flanges and Alloy Steel Flanges like Slipon Flanges, BLRF Flanges, Weldneck Flanges, Socket Weld Flanges etc.
