Manufacturer of Type 6BX Blind Flanges 15,000 PSI and API 6A Type 6BX 15000 PSI Blind Flanges in ASME B16.5 Class 150 Lb, 300 Lb, 400 Lb, 600 Lb, 900 Lb, 1500 Lb and 2500 Lb as per ASME/ ASA/ ANSI B16.5
The AISI 4130 – Type 6BX Blind Flanges 15,000 PSI is capable of withstanding pressures of up to 15,000 PSI. Forged, threaded, screwed, and plate are the most popular form of Weld Neck Flanges. Regular flanges are utilized with pipelines, while long flanges are used in process plants. AISI 4130 – Type 6BX Blind Flanges 15,000 PSI are commonly produced from forgings and butt welded to a pipe. This type of flange is extensively utilized in industrial operations such as subsea wellheads, wellhead equipment, oil exploration, oil and gas drilling, high-pressure jobs, rig projects, and many others since it is resistant to both freezing and high temperatures.
Table Of Contents
We care about client satisfaction at Rajendra Industrial Corporation, hence we strive to produce high-quality goods. We sell AISI 4130 fittings and grades all around the globe. All of our clients receive high-quality products that come with detailed instructions and accreditation.
| Specification | API 6A Flanges |
|---|---|
| Size Chart | (1/2") To (48") |
| Temperature Ratings | 150 LB To 2500 LB |
| Thickness | NPS ≤ 18 |
| ADNOC Approved Manufacturer Of Standards | ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, MSS S44, IS 2062, ISO70051, API, API7S-43, ANSI/ASME B16.5, API7S-15 |
| Face Type | Raised Face, Large Tongue & Large Male-Female And Small Male-Female, Groove And Small Tongue Groove, RTJ, Flat Face, Lap-Joint Face. |
| Forging Materials | Stainless Steel, Alloy Steel, Carbon Steel, Duplex Steel & Super Duplex Steel, Cast Iron, Inconel, Mild Steel, Hastelloy, Copper Nickel, Wrought Iron. |
| Flanges High Temperature | Above 200° Celsius (400°F) For 150 Class Or Above 400° Celsius (750°F) |
| JIS Standards | 5K, 10K, 40K, 16K 20K 30K, 63K |
| Our Top Selling Products | Lap Joint, Socket-Weld, Blind, Threaded, Weld Neck, Slip-On |
| Buy Flanges For Pipe Connection | Power Plants Industry Food Processing And Manufacturing Waterworks Systems Nuclear Power Application Municipal Pipe Systems Fossil Fuel Power Plants Oil And Gas Industry |
| Type Of Making Format | Plate /Forged/ Threaded |
| Bore Diameter | NPS ≤ 10 |
| Manufacturing Process |
|
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| AISI 4130 | G41300 | 1.7218 | - | 25CrMo4 | JIS G4105 | BS 970 | - |
Manufacturer of Type 6BX Blind Flanges 15,000 PSI and API 6A Type 6BX 15000 PSI Blind Flanges in ASME B16.5 Class 150 Lb, 300 Lb, 400 Lb, 600 Lb, 900 Lb, 1500 Lb and 2500 Lb as per ASME/ ASA/ ANSI B16.5
| Grade | Ni | C | Mo | Mn | Si | Fe | Cu | S | P | Cr |
| AISI 4130 | 0.50 max | 0.28-0.33 | 0.15-0.25 | 0.40-0.60 | 0.15-0.35 | 97.3-98.22 | - | 0.025 MAX | 0.035 MAX | 0.80-1.10 |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.85g/cm3 | 1432 C | 460 MPa | 560 MPa | 21.50 % |
| Price list of API 6A Type 6BX 15000 PSI WNRTJ Flange | US $0.5-1000 / Piece (FOB Price) |
| AISI 4130 6BX 15000 PSI Weld Neck Flanges Price in India | US $300-500 / Ton (FOB Price) |
| Price list of Alloy Steel AISI 4130 Type 6BX 15000 PSI Weld Neck Flanges | US $1-900 / Piece (FOB Price) |
| API 15000 Blind Flanges Dimensions Price | US $0.5-1000 / Piece (FOB Price) |
| API 6A 6BX 15000 PSI WNRTJ Flanges Price List | US $1-300 / Piece (FOB Price) |
| 4130 AISI Type 6BX 15000 PSI WNRTJ Flange Price Per Piece in India | US $1-800 / Piece (FOB Price) |
| Alloy Steel Type 6BX 15000 PSI 150# WNRTJ Flanges Price | US $15-900 / Piece (FOB Price) |
| Price of Alloy Steel 4130 Type 6BX WNRTJ Flanges | US $20-1500 / Piece (FOB Price) |
| ASME B16.5 AISI 4130 Type 6BX Blind Flanges 15,000 PSI | US $18-1800 / Piece (FOB Price) |
We can supply AISI 4130 Type 6BX Blind Flanges 15,000 PSI with customized Class / Pressure and sizes, view AISI 4130 6BX 15,000 PSI Blind Flanges Price.
| Size | B | OD | C | K | P | E | T | Q | X | BC | N | H | LN | HL | JL | R/RX |
| 2 1/16" | 53.2 | 215 | 3 | 124 | 95.25 | 7.9 | 46.1 | 38.1 | 104.8 | 165.1 | 8 | 26 | 109.5 | 60.3 | 43.7 | 24 |
| 2 9/16" | 65.9 | 245 | 3 | 137 | 107.95 | 7.9 | 49.3 | 41.3 | 123.8 | 190.5 | 8 | 29 | 112.7 | 73 | 54.9 | 27 |
| 3 1/8" | 81.8 | 265 | 3 | 168 | 136.53 | 7.9 | 55.6 | 47.7 | 133.3 | 203.2 | 8 | 32 | 125.4 | 88.9 | 67.5 | 35 |
| 4 1/16" | 108.7 | 310 | 3 | 194 | 161.93 | 7.9 | 62 | 54 | 161.9 | 241.3 | 8 | 35 | 131.8 | 114.3 | 88.1 | 39 |
| 5 1/8" | 131 | 375 | 3 | 229 | 193.68 | 7.9 | 81 | 73.1 | 196.8 | 292.1 | 8 | 42 | 163.5 | 141.3 | 110.3 | 44 |
| 7 1/16" | 181.8 | 395 | 6 | 248 | 211.15 | 9.7 | 92.1 | 82.6 | 228.6 | 317.5 | 12 | 39 | 181 | 168.3 | 132.6 | 46 |
| 9" | 229.4 | 485 | 6 | 318 | 269.88 | 11.2 | 103.2 | 92.1 | 292.1 | 393.7 | 12 | 45 | 223.8 | 219.1 | 173.8 | 50 |
| 11" | 280.2 | 585 | 6 | 371 | 323.85 | 11.2 | 119.1 | 108 | 368.3 | 482.6 | 12 | 51 | 265.1 | 273.1 | 216.7 | 54 |
| NPS In Inch. | DN In MM | Flange Outside Daimeter A In MM | Flange Thickness D In MM | API 6a SORF Flange Weight In KG | API 6a WN Flange Weight In KG | API 6a BLRF Flange Weight In KG |
| 1/ 2 | 15 | 88.9 | 11.2 | 0.4 | 0.5 | 0.4 |
| 3/ 4 | 20 | 98.6 | 12.7 | 0.6 | 0.7 | 0.6 |
| 1 | 25 | 108 | 14.2 | 0.8 | 1 | 0.9 |
| 1 1/ 4 | 32 | 117.3 | 15.7 | 1 | 1.3 | 1.2 |
| 1 1/ 2 | 40 | 127 | 17.5 | 1.3 | 1.7 | 1.5 |
| 2 | 50 | 152.4 | 19.1 | 2.1 | 2.6 | 2.4 |
| 2 1/ 2 | 65 | 177.8 | 22.4 | 3.3 | 4.1 | 3.9 |
| 3 | 80 | 190.5 | 23.9 | 3.9 | 4.9 | 4.9 |
| 3 1/ 2 | 90 | 215.9 | 23.9 | 4.8 | 6.1 | 6.2 |
| 4 | 100 | 228.6 | 23.9 | 5.3 | 6.8 | 7.0 |
| 5 | 125 | 254 | 23.9 | 6.1 | 8.6 | 8.6 |
| 6 | 150 | 279.4 | 25.4 | 7.5 | 10.6 | 11.3 |
| 8 | 200 | 342.9 | 28.4 | 12.1 | 17.6 | 19.6 |
| 10 | 250 | 406.4 | 30.2 | 16.5 | 24 | 28.6 |
| 12 | 300 | 482.6 | 31.8 | 26.2 | 36.5 | 43.2 |
| 14 | 350 | 533.4 | 35.1 | 34.6 | 48.4 | 58.1 |
| 16 | 400 | 596.9 | 36.6 | 44.8 | 60.6 | 76.1 |
| 18 | 450 | 635 | 39.6 | 48.9 | 68.3 | 93.7 |
| 20 | 500 | 698.5 | 42.9 | 61.9 | 84.5 | 122.0 |
| 24 | 600 | 812.8 | 47.8 | 86.9 | 115 | 185.0 |
The final process of dispatch is the most tedious of all, and heavy duty cranes are used for it. With the help of our extensive delivery chain we can ensure time critical deliveries at the behest of our esteemed clients.
Our all AISI 4130 Type 6BX 15000 PSI Blind Flanges packed with seaworthy packing method then delivery to customers, usually the packing way include wooden box, wooden pallet. We make sure that it is seaworthy, strong, waterproof and easy for loading and unloading.
| UNS G41300 WNRTJ Flanges Manufacturer | API 6A Type 6BX 15000 PSI Blind Flanges |
| AISI 4130 Type 6BX Blind Flanges 15000 PSI | API 6A Type 6BX 15000 PSI Blind Flanges Dealer in India |
| 1.7218 Blind Flanges | Alloy Steel Type 6BX 15000 PSI Blind Flanges Stockist |
| Alloy Steel AISI 4130 6BX 15000 PSI WNRTJ Flange | PN 16 API 6A Type 6BX 15000 PSI Weld Neck Flange Stockholder |
| AISI 4130 Type 6BX 15000 PSI Blind Flanges at Best Price | AISI 4130 Type 6BX 15000 PSI WNRTJ Flange Exporter |
| Alloy Steel 4130 Type 6BX WNRTJ Flanges Manufacturer | 4130 AISI 6BX 15000 PSI Weld Neck Flanges Manufacturer |
| API 6A Type 6BX 15000 PSI Weld Neck RTJ Flange Supplier in Mumbai | Type 6BX Blind Flanges 15,000 PSI Supplier in Mumbai |
| API 6A Type 6BX 15000 PSI WNRTJ Flange Supplier in Mumbai | AISI 4130 6BX 15000 PSI Weld Neck Flange Distributor in Mumbai |
| AISI 4130 Type 6BX Blind Flanges 15000 PSI Dealer | AISI 4130 6BX 15,000 PSI WNRTJ Flanges Manufacturer |
| API 6A Type 6BX Blind Flanges 5K PSI Supplier in Mumbai | Chrome Moly 4130 Blind Flanges 15000 PSI Manufacturer in India |
| 4130 Type 6BX WNRTJ Flanges 15,000 PSI Stockist in India | Alloy Steel 4130 Type 6BX Weld Neck Flanges 15,000 PSI |
| AISI 4130 Type 6BX Blind Flanges 15,000 PSI Wholesaler | UNS G41300 Blind Flanges Supplier |
| API 6A Type 6BX 15000 PSI WNRTJ Flanges Manufacturer | AISI 4130 6BX 15000 PSI Weld Neck RTJ Flange |
